Hydraulic and Pneumatic Cylinders

Hydraulic and Pneumatic Cylinders 2018-12-03T05:28:37+00:00

RICC Europe is able to offer special cylinders such as AGC and AWC capsules, telescopic and rotating cylinders, press cylinders, rotating distributors, torque cylinders, hydraulic power units, pressure multipliers, handling cylinders, winch and skidding cylinders, anti-seismic and post-tensioning devices and many more, e.g.

  • Electrode regulation cylinders
  • Furnace tilting cylinders
  • Ladle lifting cylinders
  • Tundish tilting cylinders
  • AGC –HAGC capsules (roughness and finishing stands)
  • Work roll and B.U.R. change mechanism cylinders (single rod or telescopic cylinders)
  • Torque cylinder for coil tilting device
  • Press main cylinders

The engineering of all products is developed following the client’s dimensional and operative requirements applying the latest design criteria and techniques such as solid design, parametric configuration, and F.E.M. analysis.

The standard products are available in all kinds of fastenings:

– Bore: up to 500 mm

– Stroke: up to 11.000 mm

– Construction: completely steel-made

– Rod: up to a 360 mm diameter and always deeply chromated.

– If required: induction hardened – nickel plated – nitrided – stainless steel-made – other variants

– Jackets: hoined and, if required, chromated or intruded

– Cushioning: according to request: standard or special.

– Feeding ports: various kinds (SAE – CETOP – GAS – NPT – etc.)

– Accessories: according to request: internal or external linear transducers, encoders, proximity sensors, regulation valves, balancing valves, security valves, maximum pressure valves, hydraulic blocks, etc.

The range of products includes:

  • Mill series pneumatic cylinders
  • Mill series hydraulic cylinders
  • Rotating hydraulic cylinders
  • Hydraulic plunger cylinders
  • Heavy series pneumatic cylinders
  • Heavy series hydraulic cylinders
  • 70 atm. light series hydraulic cylinders
  • DIN series hydraulic cylinders
  • ISO 6020/2 hydraulic cylinders
  • 210 atm. light series hydraulic cylinders

Also, different kinds of special products are available according to customer demands

– Please feel free to Contact us for any application that might need a hydraulic or pneumatic cylinder with high durability and extra power to be carried out.
